Print big models in one go

Zortrax M300 Plus

Large volume FDM Wi-Fi 3D printer

The Zortrax M300 Plus is a high-volume desktop 3D printer with wireless connectivity. The Zortrax M300 Plus is a 3D printer with one of the largest workspaces in its class. It works in LPD technology, Zortrax’s original approach to Fused Deposition Modeling (FDM), which guarantees the highest quality and low maintenance. Multiple Zortrax M300 Plus 3D printers can be connected to a wireless 3D printer farm that produces large models in small to medium runs.

Large workspace

Its large working area of 300 x 300 x 300 mm is enough to print large models at once.

Wi-Fi and Ethernet connection

Multiple Zortrax M300 Plus 3D printers can be connected in large networks with Wi-Fi or Ethernet. Models can also be loaded directly from a USB storage device to each of the printers. Keep an eye on the 3D printing process with a camera built into the printing chamber, or use the smart features such as filament end detection to minimize waste.

Detection of the filament end

The printer automatically enters pause mode when there is no more filament left.

Improved extruder and nozzle

A redesigned extruder and new nozzle geometry now enable 3D printing with Flex materials.

Technical Specifications

Technical Specifications

Build volume

300 x 300 x 300 mm (11.8 x 11.8 x 11.8 in)

Material container

Spool

Material diameter

1.75 mm (0.069 in)

Nozzle diameter

0.4 mm (0.016 in) – standard / 0.3 mm (0.012 in) / 0.6 mm (0.024 in)

Support

Mechanically removed - printed with the same material as the model

Extruder

Single (compatible with demanding materials like TPU or nylon)

Extruder cooling system

Radial fan cooling the extruder block; two fans cooling the print

Hotend

Single, V3

Platform

Heated; perforated and glass are applicable

Material endstop

Mechanical

Connectivity

Wi-Fi, Ethernet, USB

Technology

LPD (Layer Plastic Deposition) – depositing melted material layer by layer onto the build platform

Layer resolution

90-290 microns (for 0.4 mm nozzle)

Minimal wall thickness

450 microns (for 0.4 mm nozzle)

Platform levelling

Automatic measurement of platform points' height

Maximum printing temperature (extruder)

290° C (554° F)

Maximum platform temperature

105° C (221° F)
